Technical Specification
| Mating cycle | ≥500 |
| Mating force | ＜100N |
| Cable size | 16 to 95mm² unshielding cable Up to 4/ 0 AWG |
| Rated current | 80A to 350A |
| Rated voltage | 1500V DC |
| Withstand voltage | TUV 4260VAC/UL 6800VAC |
| Insulation resistance | ≥200MΩ (DC1500V) |
| IP rating | IP67(mated) |
| Operation temperature | -40°C to +125°C |
| Terminal | Copper alloy, silver plating |
| Housing | PA66 |
| Flammability | UL94V0 |
| EMI | Yes |
| HVIL | Yes |
